DSG51A/DSG51B hose crimping machine
The hose crimping machine DSG-51 of my factory is suitable for industry, agriculture hose crimping. This machine is small, light and easy for operation.
Model
|
Model |
DSG-51A |
DSG-51B |
|
Crimping Inside Diameter(mm) |
6----51 |
|
|
Ruler Precision(mm) |
0.02 |
|
|
Max. Crimping Force(T) |
407 |
|
|
Motor Speed(r/min) |
1420 |
|
|
Oil Pump Capacity (ml/r) |
10 |
|
|
Oil Pump Pressure (MPa) |
20 |
|
|
Overall Size(mm) |
850 X 430 X 1030 |
|
|
Power(kW) |
3 |
3.75 |
|
Weight(kg) |
240 |
260 |
